Joinery drawings in. woodWOP programs out.

DXF and PDF from the drawing office → checked woodWOP MPR for HOMAG CENTATEQ P-110 and DRILLTEQ V-200, layered nesting DXF for CENTATEQ N-500.

dxf2wop Workshop — DXF and PDF drawings converted to machine-ready CNC programs for HOMAG woodWOP

Turn joinery drawings into machine-ready CNC programs — the software finds the views, the outline, the holes and the hardware, so nobody has to re-draw every part by hand.

Request access See how it works

Built for bespoke joinery · woodWOP · HOMAG DRILLTEQ & CENTATEQ

How it works

From a drawing to a running program in three steps

No re-drawing, no re-typing coordinates. Load the drawing, check it against the original, send it to the machine.

STEP 01

Load the drawing

Drop in the DXF (and the job PDF). dxf2wop finds the face, edge and end views, the part outline and every hole — for one part or a whole batch.

STEP 02

Check against the original

See the extracted part, the 3D solid and a coverage overlay side-by-side with the source drawing. Every hole, depth and cut-out is traced back to the geometry.

STEP 03

Export machine-ready

Pick the machine. dxf2wop works out the operations and writes a woodWOP MPR (P-110 / V-200) or a layered nesting DXF (N-500) — each part routed to the machine that can run it.

Why it's safe

It tells you what it isn't sure about — before the machine finds out

A wrong depth or a flipped face is scrap. So every value the software had to infer is marked and listed for review, with the drawing evidence next to it — you decide before anything goes to the machine.

✓
Every program is read back and checkedThe generated MPR or nesting DXF is read back and compared with what was read from the drawing before it reaches the machine.
✓
Uncertain features go to review, not to scrapMissing depths, ambiguous faces and unreadable shapes are flagged for the operator instead of being invented.
✓
Nothing to install, nothing to keep updatedIt runs in your browser. Your drawings are processed on our server for your session only and are never used for anything else; the programs download to you and run on the machine without any internet.
Formats & machines

Speaks the machines you already run

Output in the formats your machines already read — nothing new to install on the machine side.

woodWOP MPR · pod-and-rail, 5-sided
Nesting DXF · layered: outline, holes, millings
CENTATEQ N-500 · nesting
CENTATEQ P-110 · 5-axis
HOMAG DRILLTEQ V-200
DXF & PDF in
Demo access

Try it on your own drawings

A private demo for a handful of workshops — it runs in the browser, nothing to install. In the demo your drawings are uploaded to our server for your session only and can be deleted on request. Send a request and we'll set you up.
